Fuzion Impact Edition
3423 - Toy Hauler Fifth Wheels
Tandem-axle, Open Concept, 23' GarageMSRP: $103,755*
| Specification Name | Specification Value |
|---|---|
| RV Type | Toy Hauler, Fifth Wheel |
| MSRP | $103,755 |
| Shipping Weight | 12,531 lb. |
| Carrying Capacity | 4,214 lb. |
| Hitch | 2,745 lb. |
| Length | 38 ft 3 in |
| Height | 13 ft 2 in |
| Toy Hauler Garage Size | 23 ft 0 in |
| Tire-Size | ST235/80R16G |
| Fresh Water | 188 gal |
| Gray Water | 44 gal |
| Waste Water | 44 gal |
| Sleeping Capacity | 7 |
| Number of Propane Tanks | 2 |
| LPG | 60 lb. |
| Refrigerator Size | 15 cu ft |
Decor
Mahogany
Click swatches for close-up view.
Decor
Smoke
Click swatches for close-up view.
Innovation Leadership
These models feature exclusive ground-breaking components and technologies from the Keystone Inovation Lab.
Blade™ High Performance Air Flow System
Keystone’s new, patented Blade™ air handling system completely re-engineers RV ductwork and vent systems to deliver an average of 20% more cooling power.
READ MORE
12V Color-Coded Wiring Standard
Learn how Keystone’s EXCLUSIVE color-coded 12V wiring is different from conventional RV wiring and why it’s a better for both owners and service technicians.
READ MORE
1 & 3-Year Limited Warranties
Two warranties and countless owner resources for additional peace-of-mind.
READ MORE
Tru-Fit™ Slide Construction
A more durable slide room design that minimizes functional motor structural stress, and resists leaking.
READ MORE
KeyTV™ Multi-source Signal Controller
No more connection guesswork or poor reception. KeyTV offers game-changing, single point control of broadcast, cable, and satellite feeds.
READ MORE
12V Distribution Center
Organizes and streamlines 12V wiring connections with disconnect option to prevent unwanted battery draw
READ MORE
| Specification Name | Specification Value |
|---|---|
| RV Type | Toy Hauler, Fifth Wheel |
| MSRP | $103,755 |
| Shipping Weight | 12,531 lb. |
| Carrying Capacity | 4,214 lb. |
| Hitch | 2,745 lb. |
| Length | 38 ft 3 in |
| Height | 13 ft 2 in |
| Toy Hauler Garage Size | 23 ft 0 in |
| Tire-Size | ST235/80R16G |
| Fresh Water | 188 gal |
| Gray Water | 44 gal |
| Waste Water | 44 gal |
| Sleeping Capacity | 7 |
| Number of Propane Tanks | 2 |
| LPG | 60 lb. |
| Refrigerator Size | 15 cu ft |
Standards & Options
Exterior
- 10"/12" I-beams w/ frame welded tie downs and 100" wide body
- Rota-Flex™ pin box
- Aerodynamic fiberglass front cap w/ lights and improved turning radius
- Aluminum constructed laminated fiberglass sidewalls
- Large panoramic tinted safety glass windows w/ black framing
- Dual-pane frameless windows
- Fiberglass front cap w/ LED lights
- Fully walkable roof
- Collapsible roof ladder
- Norco cable driven slide system w/ manual backup
- One-piece polypropylene heated underbelly (enclosed tanks and valves)
- 7,000 lb. flipped Dexter® E-Z Lube axles w/ 12" x 2" brakes on every wheel
- Leaf spring suspension system
- 16" aluminum wheels w/ G-rated tires
- Titan™ 6 point hydraulic leveling
- 30” wide entry doors
- Lippert SolidStep® w/ extra-wide first step
- Lighted pass-through storage
- Back-up camera/prep
- Battery disconnect
- Exterior convivence center
- Dual fuel 5500 generator
- Dual fuel 5500 gen
- 94 gal. fresh, 88 gal. gray, 44/88 gal. black
- Fuel station w/ 12V pump, 30-gal. tank, and static line
- 50-AMP service w/ detachable marine power cord
- Exterior shower w/ hot and cold water
- Electric awning w/adjustable arms, auto dump, and LED light strip
Interior
- Fiberglass backed linoleum floor (carpet-free)
- Extra tall slide height
- Night shades
- Designer upholstered window valances
- Hardwood cabinetry
Keystone Exclusives
- 3-year limited structural warranty
- 1-year limited base warranty
- Color-coded unified wiring standard
- 4G LTE and Wi-Fi prep
- Tuf-Lok™ thermoplastic duct joiners
- KeyTV™ multisource signal controller
- In-floor heating ducts
- Tru-fit™ slide construction
Kitchen Features
- Full-extension ball bearing drawer guides
- Deep, single basin, stainless steel sink
- High-rise faucet w/ pull-out sprayer
Appliances & Utilities
- (2) 30 lb. LP tanks
- Chill cube A/C
- Omni Chill™ 3/4 ton high efficiency A/C
- 2nd ¾ ton A/C
- 35K BTU furnace
- Girard on demand hot water heater
- Smart TV and Bluetooth® CD/DVD player w/ MP3 connection, 2 interior, and 2 exterior speakers
- 10 Cu. Ft. 12V Refrigerator
- Microwave oven
- Furrion® 3-burner gas range and stove w/ low profile hood vent
- Recessed LED puck lighting throughout
Bedroom Features
- King bed suite w/ storage
- Reading lights
- Bedside outlets/USB
- Under bed storage
- TV hook-up
- TV prep
Bathroom Features
- Pressed countertops
- Oversized shower w/ skylight
- Porcelain base foot flush toilet
Safety
- Tire Pressure Monitoring System on all tires w/ Display
- Breakaway switch and safety chains
- GFI receptacles
- Carbon monoxide detector
- Smoke detector
- Propane gas leak detector
- Fire extinguisher
Garage
- 5k interlock system w/ frame welded tie-downs
- 8’ ramp door
- Ducted A/C, ducted heat
- (2) metal ram air vents
- Dual electric beds w/ collapsible roll-over sofa
- Sliding rear patio door
